CLW5060ZYSN4 Model technical parameters | |||
Name: | CLW5060ZYSN4 | Exterior size(mm): | 6470,6320×2050×2570 |
Chassis: | NJ1061DBFT4 | Container size(mm): | ×× |
Total weight :(kg) | 6490 | Approach angle/ Departure angle(° ) | 25/12,25/14 |
Payload:(kg) | 1510,1445 | Front suspension/rear suspension(mm): | 1050/2112,1050/1962 |
Kerb Mass:(kg) | 4850(Kg) | Max Speed(km/h): | 95 |
Chassis parameters | |||
Chassis: | NJ1061DBFT4 | Axle weight: | 2400/4090 |
Number of axles: | 2 | Fuel Type: | Diesel fuel |
Wheelbase(mm): | 3308 | Fronttread(mm): | 1588 |
Max people in cab: | 2,3 | Rear tread(mm): | 1485 |
Number of tires: | 6 | Number of spring axle: | 8/9+3 |
Tire Type: | 7.00-16LT 12PR,7.00R16LT 12PR | ||
introduction: | 选装凹形平面箱体样式;后部翻转样式选装垃圾斗装置。选装无后翻转机构,选装无后翻转机构时该车总长为6320mm,对应后悬为1962mm,对应离去角为14°。随底盘选装驾驶室。驾驶室准乘人数为2人时对应额定载质量(kg)为1510,驾驶室准乘人数为3人时对应额定载质量(kg)为1445。防护材料:Q235A碳钢,连接方式:左右侧面防护采用焊接连接,后部防护由专用装置代替豁免。 |
Engine parameters | |||
Type | Manufacturer | Displacement(ml) | Power(kw) |
YN27CRD1 CY4102-CE4F 4B2-95C40 YZ4DH1-40 |
昆明云内动力股份有限公司 东风朝阳朝柴动力有限公司 安徽全柴动力股份有限公司 潍柴动力扬州柴油机有限责任公司 |
2672 3856 2545 2540 |
70 73 70 70 |
