CLW5161TSLD4 Model technical parameters | |||
Name: | CLW5161TSLD4 | Exterior size(mm): | 7880,7500×2470×3100 |
Chassis: | DFA1160LJ10D4 | Container size(mm): | ×× |
Total weight :(kg) | 15790 | Approach angle/ Departure angle(° ) | 19/12,19/11 |
Payload:(kg) | 7145 | Front suspension/rear suspension(mm): | 1230/2150,1230/2320 |
Kerb Mass:(kg) | 8450(Kg) | Max Speed(km/h): | 100 |
Chassis parameters | |||
Chassis: | DFA1160LJ10D4 | Axle weight: | 5990/9800 |
Number of axles: | 2 | Fuel Type: | Diesel fuel |
Wheelbase(mm): | 3950,4500 | Fronttread(mm): | 1858,1949 |
Max people in cab: | 3 | Rear tread(mm): | 1806,1865 |
Number of tires: | 6 | Number of spring axle: | 8/10+7 |
Tire Type: | 9.00-20 16PR,9.00R20 16PR | ||
introduction: | 1,整车长度与轴距对应关系为(mm):7880/4500/2150,7500/3950/2320。2,防护材料:Q235A碳钢,连接方式:左右侧面防护豁免,后下部防护与副梁采用焊接连接,后部防护断面尺寸(mm):50×200,后部防护离地高度(mm):440。3,ABS系统生产厂家,型号:焦作博瑞克控制技术有限公司,J ABS. 4,文字喷涂位置和车辆颜色可变化。5,选装吸尘盒和单个扫地刷装置。 |
Engine parameters | |||
Type | Manufacturer | Displacement(ml) | Power(kw) |
ISD160 43 ISD180 43 |
东风康明斯发动机有限公司 东风康明斯发动机有限公司 |
4500 4500 |
118 132 |
other parameters |
Introduction: |
more Picture: |
