CLW5251GSST4 Model technical parameters | |||
Name: | CLW5251GSST4 | Exterior size(mm): | 10350,9950×2490×3350 |
Chassis: | EQ1258VFJ1 | Container size(mm): | ×× |
Total weight :(kg) | 24900 | Approach angle/ Departure angle(° ) | 20/10,18/13 |
Payload:(kg) | 15250,14100 | Front suspension/rear suspension(mm): | 1250/3050,1450/2850 |
Kerb Mass:(kg) | 9455,10605(Kg) | Max Speed(km/h): | 85 |
Chassis parameters | |||
Chassis: | EQ1258VFJ1 | Axle weight: | 7000/17900(并装双轴) |
Number of axles: | 3 | Fuel Type: | Diesel fuel |
Wheelbase(mm): | 4350+1300,4750+1300,5350+1300,5850+1300 | Fronttread(mm): | 1960,1980 |
Max people in cab: | 3 | Rear tread(mm): | 1860/1860 |
Number of tires: | 10 | Number of spring axle: | 9/10 |
Tire Type: | 10.00-20,10.00R20 | ||
introduction: | 运输介质:水,密度:1000千克/立方米;当整备质量为9455kg时,罐体有效容积:16.01立方米;轴距/整车长/(罐体尺寸)对应关系为(mm): 4750+1300/10350/(6900/2300/1500), 4350+1300/9950/(6500/2360/1550; 当整备质量为10605kg时,罐体有效容积:14.80立方米;轴距/整车长/(罐体尺寸)对应关系为(mm): 4750+1300/10350/(6900×2250×1400), 4350+1300/9950/(6600×2300×1430)。选装同系列驾驶室,保险杠时前悬为(mm)1450对应后悬为(mm)2850;防护材料:Q235A碳钢,连接方式:左右侧面及后下部防护均采用焊接连接,后部防护断面尺寸(mm):120×50,后部防护离地高度(mm):520。ABS的型号:4S/4M,生产厂家:威伯科汽车控制系统有限公司。 |
Engine parameters | |||
Type | Manufacturer | Displacement(ml) | Power(kw) |
ISB210 40 ISDe230 40 YC6J220-46 YC6A240-46 |
东风康明斯发动机有限公司 东风康明斯发动机有限公司 广西玉柴机器股份有限公司 广西玉柴机器股份有限公司 |
5900 6700 6494 7255 |
155 169 162 177 |
other parameters |
Introduction: |
